2153 air water spray atomizing nozzle

  • 10 - 49 Pieces
    $25.00
  • 50 - 99 Pieces
    $22.00
  • >=100 Pieces
    $20.00
Model Number:
2153LC
Lead Time:
Quantity(Pieces) 1 - 100 101 - 1000 >1000
Est. Time(days) 7 12 Negotiable
Customization:
Customized packaging (Min. Order: 1000 Pieces)
Customized logo (Min. Order: 100 Pieces)
Samples:
$25.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Warranty:
1.5 years
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Energy & Mining
After Warranty Service:
Online support
Local Service Location:
none
Showroom Location:
none
Video outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
Ordinary Product
Place of Origin:
Guangdong, China
Brand Name:
JTCCO
Condition:
New
Product name:
Air Atomizing Nozzles
Material:
Brass, SUS 303
Spray angle:
30/60/80 Degree
Working pressure:
1 - 4bar
Thread size:
1/4" Female
Feeding type:
Pressure Feed
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
carton
Port
shenzhen
Lead Time :
Quantity(Pieces) 1 - 100 101 - 1000 >1000
Est. Time(days) 7 12 To be negotiated





Pressure fed air atomizing nozzle Feature



Air Atomizing Nozzles deliver an unique internal design that makes it possible for the liquid and air to mix internally producing a fine or coarse drops atomized spray.


Basically, obtaining fine atomization is done by increasing the air pressure or lowering the liquid pressure, resulting in a high ratio of air flow rate to liquid flow rate.


In the vast majority of industrial processes, air atomizing Nozzles are being used, where compressed air supplies the required energy for atomizing the liquid.

pressure fed  air atomizing nozzle Applications

1.Application: Humidty, Cooling and Dust Control
2.Spray Pattern:Full Cone and Flat Fan
3.Adjustable:Sipone Type

4.Air Atomizing Nozzle:Siphon-fed Round

5.Siphon-fed Round type: Internal Mix, Full Cone,Adjustable, Air atomizing,Mixing Air and Water

6.Pressure-fed type: Internal Mix, Flat Fan Nozzles, Air Atomizing Spray Nozzles,Mixed Air Atomizing Nozzles.

7.Material:Stainless Steel, Brass





SPRAY SET UP FEATURES

Each series is abaliable with a pressure spray set-up or siphon spray set-up
each set-up provides a specific spray pattern with a specific capacity ans spray coverage range performance.
spray set-ups are interchangeable for each nozzle series
round spray:extended full cone round spray pattern
wide angle round spray :hollow cone-type,wide angle round spray pattern
360circular spray :hollow cone-type 360 circular spray pattern
flat spray:extended flat or sheet-type s[ray pattern
deflected flat spray :extended flat or sheet-type spray diverted awat from the axis of the inlet connection
each spray set-up consists of an air cap and fluid cap

Atomization control features
achieved by adjusting the air and liquid pressure in the spray set-up
obtaining finer atomization is air pressure and or lowering the liquid pressure ,resulting in a high ratio of air flow rate to liquid flow rate.

Internal Mix Features
liquid and air are mixed internally to produce a completely atomized spray .
liquid and gas streams are not independent and a change in air flow will affect the liquid flow
internal miz uses pressure set -ups and is abailable with the following spray patterns :
360 circular spray    deflected flat spray , elliptical spray , flat spray , round spray, wide angle round spray

External mix features
liquid and air streams are mixed outside of the nozzle
air and liquid flow can be controlled independently
effective for higher viscosity liquids and abrasive suspensions
external mix can use siphon set-ups or pressure set-ups
when a siphon set-up is used  a round spray pattern is produced
when a pressure set0up is used, a flat spray pattern is produced




  Any question please feel free to call me or whatsapp available :0086-13925573754
